　　*TYPE:YLJ132S-4B25:15900.00P10:1.86Insulate:*

　　*Power:40(N.M)P:4.U:380.f:50.Name:Date:*

　　............................................................................

      *Q1=36.D1=210.0D2=135.2STATORROTOR*　

　　*Q2=28.Di1=136.0g=.40U1:380.Ty=104.51*

　　*L=105.0Leff=105.8A:1.Fd1=34.33*

　　*L1=99.8L2=99.8zf:564.0D=15.00*

　　*b01=3.50b02=1.00z:47.*

　　*bs1=6.2br1=6.90Czn:1.*

　　*Rs=4.15br2=2.40N1*d1:1.*1.18*

　　*hs1=.78br3=.00N2*d2:0.*.00*

　　*hs2=12.22br4=.00S:1.09*

　　*Hs0=.8hr0=.5Y:7.70*

　　*bt1=6.0hr1=1.7Lz:256.2*

　　*bt2=7.9hr2=18.8Gcu:4.41.2*

　　*bt3=.0hr3=.0R1:2.86762.2233*

　　*t1=11.87t2=15.17J:5.823.46/2.79*

　　*Zs1=30.00Zs2=30.0Sk:16.62*

　　*hc1=20.4hc2=22.6Se:95.09*

　　*Zc=1.Sf:.7847*

　　............................................................................

　　*kdkpkdpzfkkc*

　　*stator:.95981.0000.9598541.31.3078im=.4722*

　　*rotor:1.0270ir=1.137*

　　*Tp=106.81Fs=1.4818Ft=1.22281.3431ix=.668*

　　*Ke0=.9640Ke1=.9158Ft0=1.3109i1=1.31826.36*

　　*Fa=576324.30*

　　............................................................................

　　*mm*mmBLAT/cmATi2=1.164325.7*

　　*st:5346.015974.14.426.3237.91pcu1=.0633348.0*

　　*sc:2038.214138.74.45.8321.14pcu2=.0382210.3*

　　*rt:5494.515543.20.517.6231.73pfe=.0216119.0*

　　*.00..0.00Ps=.006033.0*

　　*rc:2254.312782.27.73.193.73pfw=.010557.8*

　　*g0:11300.97557..54324.79pg=.1396768.0*

　　*Ikw=4.82ac1=.488c2=.422AT=419.31p1=1.13676251.7*

　　*Im=2.28a*

　　............................................................................

　　*EffPfTmTstIstAJSn*

　　*.8774.86233.082.206.581464.7.0365*

　　*JB:.8500.83002.302.307.00.2718*

　　............................................................................

　　*B0Cm**3w/cm**3pSiWiHw*

　　*st:16448.3348.9.03912.92.30.082.0*

　　*sc:14893.31213.8.03138.22*

　　*Gfe=34.3(Kg)PPfe=119.0I10=2.60aP10=236.9S0=.0005*

　　............................................................................

　　*A1=251.86H1=.0130LB=105.0SB=94.1*

　　*Cx=.03882H2=.0169Dr=110.0Sr=260.*

　　*Ku1=1.0000Spu1=.3893Ku2=1.0Spu2=.500rb=.0201Rb=1.581*

　　*KL1=1.0000SpL1=.8164KL2=1.0SpL2=1.272re=.0082Re=.643*

　　*Sp1=1.2057Sp2=1.772r2=.0282R2=2.22*

　　............................................................................

　　*Xs1=.4330cxXs1s=.4258cxKcc=1.38*

　　*Xd1=.6949cxXd1s=.2078cxXXo=.93kax=.000*

　　*Xe1=.5798cxXe1=.5798cxrro=1.16kar=.000*

　　*X1=.0663X1s=.0471ATst=2984.*

　　*Xs2=.7535cxXs2s=.6185cxBLg=46627.Kzg=.299*

　　*Xd2=.8354cxXd2s=.2499cxBls1=4879.Kzs1=.918*

　　*Xe2=.1968cxXe2=.1968cxBls2=20226.Kzs2=.534*

　　*Xsk=.5012cxXsks=.1499cxCs1=.31*

　　*X2=.0888X2s=.0472Cs2=.87*

　　*X=.1551Xst=.0938dspu1=.0200*

　　*r1=.0364r2s=.0315dspu2=.2332*

　　*R1=2.8676rst=.0672spl2s=1.1873*

　　*r2=.0282zst=.1154sp1s=1.1857*

　　*sp2s=1.4541*

　　----------------------------------------------------------------------------

以上為實心轉子力矩電機電磁設計方案一般理論通過均可完成。極少型號需要修正。
